Fire Pumpsets

Aline range of Package Fire Booster Pumpsets were developed for the growing demand in specialised turn-key systems that are fully compliant with relevant Australian standards.

Fire Booster Pumpsets are available in diesel and electric drive configurations, assembled on a common fabricated base with pipework manifolds, valves, controls and accessories to provide a fully automated system complying with AS2941.

Systems are engineered and fabricated in strict adherence to the relevant fire codes. Support services are provided from initial engineering assistance through to on-site commission and after sales service.

Aline Logo - Pumping with Innovation 2

Single Diesel

Features & Benefits

  • A full range of reliable diesel engines available
  • Tornatech control panel, suction and discharge manifolds, valves and jacking pump.
  • Fuel tank, batteries, and interconnecting wire looms.
  • Options available:
    • Weatherproof cabinets
    • Galvanised baseplates
    • Skid packages complete with suction/discharge/relief valve
    • Variable speed control

Dual Diesel

Features & Benefits

  • A full range of reliable diesel engines available
  • Tornatech control panel, suction and discharge manifolds, valves and jacking pump.
  • Fuel tank, batteries, and interconnecting wire looms.
  • Options available:
    • Weatherproof cabinets
    • Galvanised baseplates
    • Skid packages complete with suction/discharge/relief valve
    • Variable speed control

Single Electric

Features & Benefits

  • Tornatech control panel
  • Reliable electric motors
  • Factory wired and flow tested prior to dispatch
  • Fully automatic
  • Compact and easy to install
  • Built to AS2941

Diesel Electric

Features & Benefits

  • Tornatech control panel, suction and discharge manifolds, valves and jacking pump.
  • Reliable electric motors/diesel engines
  • Factory wired and flow tested prior to dispatch
  • Fully automatic
  • Compact and easy to install
  • Built to AS2941
  • Fuel tank, batteries, and interconnecting wire looms.
  • Options available:
    • Weatherproof cabinets
    • Galvanised baseplates
    • Skid packages complete with suction/discharge/relief valve
    • Variable speed control

Single Enclosure

Features & Benefits

Aline Pumps Enclosed Fire Protection Pumpsets are the perfect solution when space is limited. Our Fire Pump Sets are customized to your needs and are manufactured to the highest quality and adhere to all relevant standards. Aline Pumps enclosures can fit in with any aesthetic and remove the need for onside sheds.

  • Full height access door to panel
  • Pre-wired external strobe and bell
  • Professional locking handles
  • Ventilated to meet the pumps requirements
  • Full lifting capacity
  • Heavy duty base frame
  • Drains fully plumbed to common drain
  • All pressure lines fully plumbed
  • Pressure switches and test assemblies fully mounted and pre-plumbed in stainless steel lines
  • Muffler guards as per AS2941-2013
  • Drains fed into tundishes
  • All internal wiring complete with jacking pump, main pump, and lighting factory wired to a distribution board
  • Internal lighting installed and wired
  • Pre lagged exhaust
  • Fully plumbed, and sealed exhaust system complete with rain cap Full opening doors on each side for serviceability

Dual Enclosure

Features & Benefits

Aline Pumps Enclosed Fire Protection Pumpsets are the perfect solution when space is limited. Our Fire Pump Sets are customized to your needs and are manufactured to the highest quality and adhere to all relevant standards. Aline Pumps enclosures can fit in with any aesthetic and remove the need for onside sheds.

  • Full height access door to panel
  • Pre-wired external strobe and bell
  • Professional locking handles
  • Ventilated to meet the pumps requirements
  • Full lifting capacity
  • Heavy duty base frame
  • Drains fully plumbed to common drain
  • All pressure lines fully plumbed
  • Pressure switches and test assemblies fully mounted and pre-plumbed in stainless steel lines
  • Muffler guards as per AS2941-2013
  • Drains fed into tundishes
  • All internal wiring complete with jacking pump, main pump, and lighting factory wired to a distribution board
  • Internal lighting installed and wired
  • Pre lagged exhaust
  • Fully plumbed, and sealed exhaust system complete with rain cap Full opening doors on each side for serviceability

Vertical Turbine

Features & Benefits

Vertical lineshaft pumps with submerged pump bowl, lineshaft and drive unit on the surface for installation in deep wells or tanks. Featuring an extremely solid and reliable construction design, they ensure great flexibility in application. The technical characteristics and broad range of versions make this series ideal for pumping services in the sectors of water supply, industry, private and consortium irrigation and in fire-fighting systems. These machines can be controlled both by electric motors or diesel engines and they ensure unequalled service efficiency.

Hydrant Test Systems

Features & Benefits

Aline’s innovative boost testing system is a leap forward in the area of the AS2941 required boost testing of a buildings fire systems. Replacing the traditional method of using a pump truck, this unique product can be trailer or ute mounted and is easy to set up and begin testing.

  • Portable – easy to move from site to site
  • Trailer or ute mountable
  • High performance pumpset
  • Small high head pump also included for line pressurisation
  • Multiple outlet/inlet connection options and fitting types
  • Easily transported via forklift
  • Solar panel array included for battery charging on the go



Specifications

  • Available with 34-89kW range of Diesel Engines
  • Flow ranges from 3l/s to 30l/s
  • Output pressure from 500-2000kPa
  • Electric start with remote start options
  • Dedicated control panel with variable speed drive options available

Jacking Pumpsets

Features & Benefits

Aline manufactures and stocks a large range of capable jockey pump systems for use in conjunction with our range of diesel and electric Fire Pumps. Built with reliable and high quality components, the range spans from smaller low head systems right through to extremely high head units suitable for use in large buildings or high pressure applications. All units are built to relevant Australian standards and specifications in our Sydney manufacturing facility.
